Overview of Peripheral Arterial Duplex Assessment, Protocols, and Interpretation

Peripheral arterial disease (PAD), a condition which affects 3% to 5% of adults over 40, can lead to serious health issues. This disease causes blood vessels to narrow, mainly in the legs, making it harder for blood to circulate. People with PAD often have heart problems and a higher risk of strokes as well. Common symptoms may include cramping pain, feelings of intense coldness in lower legs, ulcers on feet or legs, and is some cases, gangrene.

Initially, a non-invasive procedure called Duplex ultrasonography, or DUS for short, is used to diagnose PAD. This method uses sound waves to create images of the blood vessels. It doesn’t require any kind of special dye to be injected and allows the results to be easily stored and reproduced. However, for patients who are obese, gas in the bowel may make it difficult to view certain blood vessels and the images must be examined carefully.

DUS can provide detailed images, and it can also measure the speed of blood flow through the vessels. Analyzing how the blood speed varies over time can offer valuable information to doctors. Importantly, the results of DUS should be combined with blood pressure readings from different parts of the leg to give a clear picture of how the arteries are working and how serious the disease may be.

To get a very comprehensive picture of the disease, PAD diagnosis also involves a range of other tests. Some tests, like measuring pressure in different parts of the leg or working out how the amount of oxygen in the skin changes, help us understand the condition of the blood vessels. On the other hand, detailed imaging scans, like CT scans, MRIs, and angiography (which uses special dye injected into the body and X-rays to show up blood vessels), give a detailed look at the shape and arrangement of the blood vessels.

Overall, DUS is a very versatile tool in diagnosing PAD. It gives crucial details such as where the narrowing of arteries is, the speed of the blood flow and even the volume of blood flowing through. This makes it a very helpful tool in planning how to improve blood flow in people with PAD, as it helps determine exactly where the problems are and their severity. DUS is also useful in monitoring patients who’ve undergone procedures like ballooning of arteries (angioplasty), stent placement in the arteries, or bypass operations.

Anatomy and Physiology of Peripheral Arterial Duplex Assessment, Protocols, and Interpretation

The large artery in your abdomen, called the abdominal aorta, splits into two paths at the level of your lower back. These paths are known as the common iliac arteries. These iliac arteries move towards the front of your body, crossing the common iliac vein.

Each common iliac artery then splits again into an internal and external iliac artery by your hip joint. The external iliac artery, being larger, runs through the pelvis along the side of a muscle called psoas. Before it passes under a part of your hip called the inguinal ligament, it sends out two smaller offshoot arteries, called the inferior epigastric artery and the deep iliac circumflex artery. When it finally goes under the inguinal ligament, it changes its name to the common femoral artery and then splits into two more arteries.

One of these, called the superficial femoral artery, is the main supplier of blood to your thigh. It continues down your leg and through a tunnel of muscles called the adductor canal. When it comes out of this canal, it is now called the popliteal artery, which also splits to become two more arteries – the anterior tibial artery and the tibioperoneal trunk – located in the top part of your calf.

The anterior tibial artery brings blood to the front part of your lower leg and ends at your ankle as the dorsalis pedis artery. The tibioperoneal trunk splits into the posterior tibial artery and common peroneal artery. The posterior tibial artery provides blood to the back of your calf, moves behind your medial malleolus (inner ankle bone), and forms the arteries that supply blood to your foot. The peroneal artery supplies blood to the side of your calf and runs behind your fibula (the lesser of the two lower leg bones).

When doctors need to study the blood flow in these arteries, they often use imaging methods that don’t require any surgery, such as Doppler Ultrasound (DUS). This technique uses sound waves to create images and measures blood flow speed. Here, and in other imaging techniques, the doctor needs to evaluate various segments of arteries in the lower leg, including the common femoral artery, superficial femoral artery, and the popliteal artery, plus others as needed.

In DUS, certain identifiable features help the doctor distinguish between veins and arteries. Arteries usually have rounded shapes, visible walls which can be slightly squeezed, and are generally smaller in size.

A specific pattern called the triphasic arterial waveform emerges in DUS, signifying the varying speed of blood cells in an arterial flow. It peaks quickly during systole (when your heart is contracting), reverses during early diastole (when your heart is relaxing), and flows slowly during late diastole (also a relaxation phase). This pattern is seen due to the movement of red blood cells, the elasticity of arteries and small caliber vessels, and capillaries.

Understanding the frequency of sound waves and the angle at which they hit structures in the body are essential for high-quality ultrasound images. For example, high-frequency sound waves at 90 degrees are best for imaging shallow structures. Improved imaging can be acquired by using Doppler mode with B-mode, enabling doctors to determine the relative speed and direction of blood flow.

The typical arterial blood flow pattern usually displays three stages called triphasic. This reflects that the red blood cells move at a steady speed throughout the heart cycle resulting in a smooth flow pattern. However, when blood cells start to exhibit varying speeds, possibly due to increased resistance, the late diastolic wave decreases or even disappears.

From the Doppler velocity waveforms, doctors may discern between different levels and types of blockages in the artery. For example, the appearance of biphasic arterial Doppler velocity waveform suggests a potential blockage in the artery while the monophasic Doppler waveform is typically indicative of multiple blockages.

Why do People Need Peripheral Arterial Duplex Assessment, Protocols, and Interpretation

A Doppler ultrasound of the arteries in your body’s periphery (those not in your heart or brain) might be recommended by a doctor in several cases. Here are a few reasons why this test might be suggested:

  • If you’re showing symptoms of Peripheral Artery Disease (PAD). PAD is a condition where the arteries that carry blood to your extremities become narrow or blocked. Symptoms might include pain in your legs when you exercise, having a hard time walking, skin discoloration, weak pulses in your legs, and wounds that won’t heal.
  • If you have had a certain kind of heart surgery and your doctor wants to monitor the surgical site. They might want to check if a graft (a piece of healthy blood vessel that was used to replace a diseased one) is likely to clot and block blood flow.
  • If you have had an angioplasty (a procedure to open up a narrowed or blocked blood vessel), a thrombectomy (surgery to remove a blood clot), or a stent placement (a tube used to keep arteries open), your doctor might use the Doppler ultrasound to check how well these procedures have worked.
  • If you have artery narrowing, hardening of the arteries (atherosclerosis), or other disorders that block blood flow, this test can help monitor the progress of these conditions.

This test might also be used to assess blood vessel issues such as aneurysms (unusual swelling or bulges in the wall of an artery), fistulas (abnormal connections between arteries and veins), and malformations (birth defects in vessels). Additionally, it might be used to map out arteries before surgery, or to evaluate injuries to the arteries from accidents.

Furthermore, a Doppler ultrasound can also help in understanding diseases not caused by the hardening of arteries—like popliteal entrapment syndrome (a position-dependent compression of the popliteal artery in the legs), external iliac artery endofibrosis (thickening of the artery wall in the leg), lower-extremity inflammatory vasculitides (inflammation and damage to blood vessels in the skin or other body organs), and vessel dissection (a tear in the artery wall).

This imaging is also helpful in diagnosing and treating a condition called peripheral arterial embolization, which occurs when a blood clot blocks an artery in the hand, arm, foot, or leg.

Equipment used for Peripheral Arterial Duplex Assessment, Protocols, and Interpretation

Ultrasonography, or ultrasound, uses different methods to look at how blood flows in the body. These include color Doppler imaging, pulsed Doppler, spectral analysis, power Doppler imaging, B-flow imaging, and high-resolution B-mode imaging. In simple terms, these are all techniques designed to show images of arteries and how blood moves through them.

For testing blood flow in the arteries of the arms and legs (a peripheral arterial ultrasound), a special device called a real-time scanner is used with a stick-like tool called a transducer. These devices can create and display images of your arteries in real time. It’s generally better to use a straight (linear) transducer over a curved transducer because it can give deeper and clearer images.

For an average-sized adult, typically a 5-MHz linear transducer is used. 3.5-MHz probes, another type of transducer, are best suited for interventions in the iliac artery (found in the pelvis), while 5-MHz probes are best for interventions in the common femoral artery (found in the thigh). These interventions include procedures like percutaneous transluminal angioplasty (PTA), a procedure to open blocked or narrowed blood vessels. Depending on the individual and where in the body the imaging is taking place, higher frequency probes (7.5 to 10 MHz) or lower frequency (3 MHz) probes may be used.

Research shows that duplex ultrasound (DUS) – a type of ultrasound that shows structure and movement – would require both curved and linear array transducers. These tools should use 3.5- to 7-MHz imaging frequencies to achieve high-resolution images of the abdomen and lower leg arteries.

When it comes to displaying the results of a Doppler ultrasound, there are two primary options: color flow Doppler imaging and spectral Doppler imaging. The former shows the average speed of blood flow as a color map on a gray-scale tissue image. The latter shows how blood flow velocity changes over time within a specific area. Spectral Doppler imaging provides additional information like the fastest velocity during the heartbeat cycle, spectral content, and range of velocities.

Who is needed to perform Peripheral Arterial Duplex Assessment, Protocols, and Interpretation?

Ultrasound tests of the blood vessels away from your heart, known as peripheral arterial ultrasounds, are mostly carried out by technicians with special training in ultrasound technology. Nonetheless, these tests can also be conducted by any healthcare workers who have the right training. Skilled healthcare providers can use a handheld device to perform a quick ultrasound right at the patient’s bedside, which can assist doctors in deciding the priority of patient’s treatment, something referred to as ‘triage care’.

How is Peripheral Arterial Duplex Assessment, Protocols, and Interpretation performed

When doing a duplex ultrasound on the leg, the patient is usually made to lie down with the hip and leg turned slightly outward. The ultrasound starts at the crease in your groin where the ultrasound tool is placed horizontally over the main artery in your thigh. A common image of this would look like “Mickey Mouse”, illustrating the main and branch arteries and the vein just below the crease. When the ultrasound tool is moved down the leg, it shows a Y-shape in the arteries.

Continuing down the leg, the ultrasound will next focus on the artery behind your knee, which is done with the knee bent. The ultrasound will typically start at the hollow of the knee and then move upwards. Whether the patient is made to lie on the left side or stomach can help the doctor see all the arteries in this area, including the main artery and the arteries going to the calf muscles and the foot.

The main artery behind the knee can be found in the center of the hollow of your knee, between the two heads of the calf muscle. Looking at the artery going to the calf behind the inner ankle starts from the bottom. The artery going to the outside of the calf along the bone of your leg can also be seen. The artery going to the front of your leg can be looked at by following the path of the artery from the joint of the foot and ankle and moving upwards, or starting at the flat part of the leg bones and moving downwards.

To look for blockages,
Special readings such as the width of the artery, thickening of the wall, and composition of the plaque are taken from images taken from the length of the artery where blockages are suspected. When looking for significant blockages of 50% to 99%, the doctor needs to make sure that the speed of the blood flow at the site of the block is at least twice that of a more distant segment. This ratio provides a more accurate evaluation of arterial blockage than absolute measurements. After a significant blocking the blood flow slows down considerably, and will show a delay in reaching the peak speeds, which is referred to as a slower and smaller pattern. Identifying this pattern is important as it indicates a high-grade blockage or complete blockage up the artery. If blockage occurs, there will be no flow within the artery segment. If there are no alternate routes, the segment before the blockage will display high-resistance signals. However, if alternate routes are present, a low-resistance, low-velocity slower and smaller flow pattern will appear in the new segment. It is also important to note the estimated lengths of the blocked or occluded segments during the evaluation.

Evaluation of pseudoaneurysms or an outpouching in the blood vessel should take note of their size, the measurements of the remaining lumen, and the length and width of the surrounding channel. This can be done by using grayscale and color Doppler imaging. The latter can show the unique ‘yin-yang’ sign caused by the swirling blood within the affected area.

A femoral pseudoaneurysm typically shows a unique ultrasound feature wherein the stem of the aneurysm displays a “to-and-fro” flow pattern while the sac empties during the contraction and relaxation of the heart. The flow pattern appears bidirectional when examining the communicating channel using special Doppler waveforms. The waveform also displays a rapid flow upstroke, an exaggerated retardation, and an elongated reverse flow component.

An arteriovenous fistulae (AVF) or abnormal connection between an artery and a vein are seen less frequently. To assess AVF using ultrasound, taking a Doppler waveform from the artery located before, at, and after the site of the fistula is crucial. Additionally, flow within the fistula and the draining vein should be noted. Color Doppler is useful in identifying the level of communication as the flow disturbance in the fistula creates color in the surrounding tissues due to pressure changes and transmitted vibrations, termed a color bruit. Blood flow from a high-pressure artery to a low-pressure vein results in spectral broadening, increased flow speeds, and continuous forward flow throughout the cardiac cycle.

When examining the cardiac cycle within an AVF, spectral Doppler may show increased flow within the vein, indicating arterialization. To detect AVF formation, look for a high-speed flow jet with a peak flow speed greater than 300 cm/s. In cases of femoral artery puncturing, the external iliac artery flow signals might show increased speeds, and altered flow signal before the site of the AVF.

While evaluating peripheral aneurysms, their location and largest diameter of the aneurysm should be noted on grayscale images. If present within the aneurysm, their openness and internal blood clot should be noted using color Doppler.

What Else Should I Know About Peripheral Arterial Duplex Assessment, Protocols, and Interpretation?

Peripheral Artery Disease, or PAD, is a condition that affects a considerable number of people, posing significant risks to their health and even life. The most intense form of PAD is called critical limb ischemia. This condition causes severe, ongoing pain due to poor blood flow. A common sign of systemic atherosclerosis, a disease where plaque builds up in the arteries, PAD often manifests as lower leg problems. People with PAD have a 2-4 times higher risk of experiencing a heart attack, stroke, or heart disease.

Identifying PAD early is crucial. It allows for treatment and adjustments to lifestyle or habits that could reduce the risks associated with heart-related diseases.

Doppler Ultrasound Scan (DUS) is an accessible, non-invasive process to visualize the arteries in the lower legs. When combined with other non-invasive tests, DUS can efficiently screen for PAD. It can provide details about the position and intensity of PAD, which can guide the best treatment approach. DUS is also helpful for monitoring the progression of PAD and the effectiveness of treatments.

Frequently asked questions

1. How does a Peripheral Arterial Duplex Assessment help diagnose and monitor Peripheral Arterial Disease (PAD)? 2. What other tests or imaging scans may be necessary to get a comprehensive picture of my PAD? 3. Can you explain the different patterns and waveforms that are seen in a Doppler ultrasound of the arteries? 4. What specific information can be gathered from the Doppler ultrasound results to determine the severity of blockages or other issues in the arteries? 5. How can the results of the Doppler ultrasound help guide treatment options for PAD, such as angioplasty or bypass surgery?

Peripheral Arterial Duplex Assessment, Protocols, and Interpretation can affect you by providing doctors with a non-invasive method to study the blood flow in your arteries. This technique, using Doppler Ultrasound, allows doctors to evaluate various segments of arteries in your lower leg and determine the relative speed and direction of blood flow. By analyzing the Doppler velocity waveforms, doctors can discern between different levels and types of blockages in the artery, which can help in diagnosing and treating vascular conditions.

There are several reasons why someone may need Peripheral Arterial Duplex Assessment, Protocols, and Interpretation: 1. Diagnosis of Peripheral Arterial Disease (PAD): Peripheral Arterial Duplex Assessment is a non-invasive imaging technique that can help diagnose PAD. It provides detailed information about the blood flow in the arteries of the legs, helping to identify any blockages or narrowing that may be causing symptoms such as leg pain or cramping. 2. Evaluation of Arterial Stenosis: Peripheral Arterial Duplex Assessment can also be used to evaluate the severity of arterial stenosis (narrowing) in the legs. This information is important for determining the appropriate treatment options, such as medication, lifestyle changes, or surgical intervention. 3. Assessment of Grafts and Stents: For individuals who have undergone arterial bypass surgery or stent placement, Peripheral Arterial Duplex Assessment can be used to assess the patency (openness) and function of these grafts or stents. This helps to monitor the success of the procedure and detect any complications or re-narrowing. 4. Monitoring Disease Progression: Peripheral Arterial Duplex Assessment can be used to monitor the progression of PAD over time. By comparing the results of multiple assessments, healthcare providers can determine if the disease is stable, improving, or worsening. This information is crucial for making treatment decisions and adjusting medications or interventions as needed. 5. Planning for Interventional Procedures: If a person with PAD requires an interventional procedure, such as angioplasty or stent placement, Peripheral Arterial Duplex Assessment can help guide the procedure. It provides real-time imaging of the arteries, allowing the healthcare provider to visualize the blockages and navigate the catheter or guidewire more accurately. Overall, Peripheral Arterial Duplex Assessment, Protocols, and Interpretation are essential for diagnosing and managing PAD, evaluating arterial stenosis, monitoring disease progression, and guiding interventional procedures. They provide valuable information about the blood flow in the legs, helping healthcare providers make informed decisions about treatment and care.

Someone should not get a Peripheral Arterial Duplex Assessment, Protocols, and Interpretation if they do not have any symptoms or risk factors for peripheral arterial disease, as it may not be necessary and could lead to unnecessary testing or treatment. Additionally, if the individual has a known allergy to the contrast dye used in the procedure, they should not undergo this assessment.

The text does not provide information about the recovery time for Peripheral Arterial Duplex Assessment, Protocols, and Interpretation.

To prepare for a Peripheral Arterial Duplex Assessment, Protocols, and Interpretation, the patient should be aware of the symptoms of Peripheral Artery Disease (PAD) such as leg pain, difficulty walking, skin discoloration, weak pulses, and non-healing wounds. They should also inform the doctor if they have had any heart surgeries, angioplasty, thrombectomy, or stent placements. Additionally, the patient should be prepared for non-invasive tests such as Doppler ultrasound to assess blood flow in the arteries and provide detailed images for diagnosis and treatment planning.

The text does not provide information about the complications of Peripheral Arterial Duplex Assessment, Protocols, and Interpretation.

Symptoms that require Peripheral Arterial Duplex Assessment, Protocols, and Interpretation include pain in the legs during exercise, difficulty walking, skin discoloration, weak pulses in the legs, wounds that won't heal, and conditions such as artery narrowing, hardening of the arteries, or other disorders that block blood flow. Additionally, this assessment may be needed for monitoring the surgical site after certain heart surgeries, evaluating the effectiveness of procedures like angioplasty or stent placement, assessing blood vessel issues like aneurysms or malformations, mapping out arteries before surgery, and diagnosing and treating conditions like peripheral arterial embolization.

There is no specific information provided in the given text regarding the safety of Peripheral Arterial Duplex Assessment, Protocols, and Interpretation during pregnancy. It is always important to consult with a healthcare professional before undergoing any medical procedures or tests during pregnancy to ensure the safety of both the mother and the baby.
