Overview of Prisms

A prism is a clear, three-sided object that can bend light. Each prism has a pointed end, or apex, and a flat bottom, or base. When light shines into a prism, it changes direction and comes out moving towards the base of the prism. The amount this light bends, or deviates, depends on the “strength” of the prism, which is measured in units called “prism diopters.”

The term “prism diopters” was first used by Charles Prentice to describe how much a prism can make light change direction. If a prism has a power of one prism diopter, it can make light shift by one centimeter at a right angle to its original path if that light traveled one meter from the prism. The strength of a prism in prism diopters is shown with the letter D. So, a 2D prism can make a light ray shift by two centimeters, at a right angle to its starting direction, one meter from the prism.

There’s another way to measure the strength of a prism, called “centrads,” but it’s not used as much as prism diopters. The symbol for centrads is Ñ. One centrad means the prism can make light shift one centimeter at a right angle to its original path along a curved line (or arc) one meter from the prism.

The way light changes direction when it passes through a prism also depends on the type of material the prism is made from, and how the prism is positioned. It’s important to note that although the light moves towards the base of the prism after passing through it, it makes things seem to move towards the apex, or tip, of the prism. Therefore, if we’re testing someone’s vision with a prism, their eye will seem to shift towards the apex of the prism.

Anatomy and Physiology of Prisms

When light passes through a prism, it follows a law called Snell’s law. This means that the light bends towards the base of the prism, causing it to shift away from the base and towards the pointed top of the prism. This change in direction is known as the angle of deviation.

When a prism is placed in the air, how much the light bends, or the angle of deviation, is affected by three things: the angle the light hits the prism (angle of incidence), the angle of the prism where the light hits it (refracting angle of the prism), and the composition of the prism itself (refractive index of the prism material).

What happens to the light after it passes through a prism?

– The size of the image doesn’t get bigger or smaller (no magnification/minification of the image)
– The convergence or divergence of the light rays doesn’t change (no change in vergence of the rays)
– The light splits into its different colors (disperses incident pencil rays into component colors)
– An upright image is formed that looks like it’s behind the prism (a virtual, erect image is formed)
– The image appears to shift in the direction of the point of the prism (the image should deviate through the apex of the prism)

A formula called Prentice’s rule is used to measure the amount of deviation caused by the prism. In this formula, D = cF, where D is the deviation, c is the image displacement in cm, and F is the power of the lens.

The amount the light bends when it goes through a prism depends not only on the power of the prism, but also what material the prism is made of, and how the prism is being held. A prism can be held in three ways – position of minimum deviation, Prentice position, and frontal position.

– The position of minimum deviation is when the angle the light hits the prism is the same as the angle it exits the prism. This is typically used with plastic prisms, but it can be difficult to achieve in real-life situations.
– Prentice position is when the prism is held so that it’s at a right angle to the line of sight. This is typically used with prisms made of glass for eye tests or treatments.
– The frontal position is when the prism is held parallel to the front of the face.

Why do People Need Prisms

Prisms in eye care are used for both diagnostic and treatment purposes. Prisms are made from glass or plastic and come in multiple forms, such as loose prisms, prism bars, prisms in a trial set, or Fresnel prisms. The power of prisms varies across these models. For example, prisms in a trial set can be anywhere from ½ to 12 D (diopters). Prism bars and Fresnel prisms can have a range from 1 to 40 D, and loose prisms can range from 1 to 60 D.

Diagnosing Eye Conditions with Prisms:

Prisms are used in many eye-related equipment such as the slit lamp biomicroscope, applanation tonometer, gonioscope, keratometer, pupillometer, phoropter, and ophthalmoscopes (all are types of tools used to examine the eye). They can help in:

* Measuring squint (eyes not properly aligned) using the prism cover test or Krimsky method.
* Determining squint through the use of a Maddox rod (a device used to test vision).
* Assessing the maximum limit to which the eyes can remain aligned (fusional reserve amplitudes).
* Evaluating torsion (twisting of the eye).
* Conducting the four prism diopter test to diagnose microtropia (small misalignment of the eyes).
* Identifying abnormal correspondence between the two eyes.
* Predicting the chance of seeing double (diplopia) after proposed squint surgery.
* Evaluating head posture after nystagmus surgery (an operation to fix uncontrolled eye movements).

Treating Eye Conditions with Prisms:

Prisms can also be used in treatments like:

* Helping patients with weak eye convergence (where the eyes move towards each other) to strengthen their convergence capacity.
* Assisting patients who struggle with their eyes moving apart, or divergence, to improve this skill.
* Helping relieve double vision in patients with small vertical squints, a condition where the balance of eye muscles is off (decompensated phorias), or paralytic squints.
* Reducing the speed of uncontrolled eye movements in patients with nystagmus.
* Increasing the field of vision for people with partial blindness in one half of their vision (hemianopia).
* Fresnel prisms are used for patients with bilateral temporal hemianopia (loss of outer (temporal) half of vision in both eyes), glaucoma, retinitis pigmentosa (a group of rare genetic disorders that involve a breakdown and loss of cells in the retina), brain injury, and stroke.
* They are also used in reading glasses for patients who are bedridden.

When a Person Should Avoid Prisms

Prisms are widely used in an area of eye care called orthoptics, which deals with diagnosing and treating vision problems related to how the eyes move and work together. Although there are no specific reasons a prism shouldn’t be prescribed, we still must keep several things in mind like the cost and if it’s suitable for each individual patient. This is because prism lenses can tricky when:

* The eyes are adapting to the prism – Our eyes are incredibly adaptable, and sometimes they can get used to the prism lens. This could make the original vision problem worse, which is why the eye professional needs to keep an eye on this.
* The original eye problem is getting worse – If the underlying eye condition is still progressing, then the patient’s eyes might adjust to the prism, which could make the original vision problem come back.

Also, when using prisms continuously, the original vision problem may increase over time and become permanent. If a patient has a condition where the center of the eye’s vision (called the fovea) moves because of a disease, this creates a difference in vision between the two eyes leading to double vision. Prism glasses can help with the double vision for a bit, but the double vision usually comes back over time as the eyes adjust.

Equipment used for Prisms

Prisms can come in different forms when used in eye care. Some of these include:

Dispersive prisms like Abbes and triangular prisms,
Polarizing prisms such as Nicol and Wollaston prisms, and
Reflective prisms like Penta, Porro, and Dove prisms.

Nicol Prisms are made from a type of crystal known as calcite. The crystal is cut diagonally and the two pieces are glued together using a special optical glue with the ability to bend light in a specific way. They create two different types of light beams. Nicol Prisms are used in a tool which helps understand the properties of light, known as Haidinger brushes.

Wollaston Prisms are made up of two right-angled prisms, created from reflective surfaces like quartz or calcite, glued together to make a rectangular unit. A beam of light entering the prism comes out split into two different light beams. Wollaston Prisms are used in keratometers, which are instruments used to measure the curvature of the eye’s surface.

Porro Prisms, on the other hand, are used to change the direction of an image. It rotates the image by 180 degrees. These prisms are commonly used in slit lamps, which are devices that allow eye doctors to examine the eye’s surface and other structures. When a beam of light passes through this type of prism, the image turns around completely and moves to a different location.

Prisms used for vision therapy come in several types such as loose prisms, prisms in a trial frame, prism bar, Fresnel prisms, rotating prisms, Risley double prisms which consist of 2 rotating prisms of the same strength on a rotating frame, prism flippers, and vari prisms where the strength can be altered by rotating two glasses.

Fresnel Prisms are created from a material called polyvinyl chloride. They consist of many tiny prisms stacked in a way that one sits on top of the other, with the pointed end of one next to the flat end of the next. They can be stuck at the base surface of glasses and create the effect of a single larger prism. The Fresnel prism is placed so that the flat end of the prisms is directed towards the side of the eye with vision issues.

Who is needed to perform Prisms?

Eye specialists known as orthoptists, optometrists, and ophthalmologists all need to understand the basics of something called prisms. Prisms are used in glasses to correct certain vision problems. They need to understand how a prism works in glasses, and how moving the lens of the glasses can create a different prismatic effect.

After doing a detailed eye exam, they use this knowledge to give you the right prescription. The prescription might include prisms, either on their own or with other vision corrections.

There are two ways these specialists might write down the prism prescription for your glasses. They can say how strong the prism needs to be and which way it should be oriented. For example, they might write something like “Right – prism 3 UP 2out, Left – prism 2 DN 2 out”. This means your right lens needs a prism of 3 “upwards” and 2 “outwards”, and your left lens needs a prism of 2 “downwards” and 2 “outwards”.

Alternatively, they can use a method that uses a 360-degree scale to describe the direction of the prism. In this method, 0 is to the left, 90 is up, 180 is to the right, and 270 is down. So, the same prescription could be written as “Right – prism 3 base 90 2 base 180, Left – prism 2 base 270 2 base 0”. This means exactly the same thing as the previous example, just written in a different way.

Any other corrections for near or far sightedness is usually written down separately.

Preparing for Prisms

When making glasses, it’s important to understand how curved lenses, or spherical lenses, create a prism-like effect. This effect is particularly important if you’re a patient with vision problems that need correcting.

Here’s an easy way to imagine it: a thicker lens, which is usually for farsighted people, works like two prisms stuck together at their bases. A thinner lens, for nearsighted people, works like two prisms stuck together at their pointy ends.

This means that the type of lens you’re wearing can affect how much deviation or blurriness you might experience. You’ll find more deviation with a thinner lens and less with a thick lens.

To understand this better, you can refer to something called Prentice’s Rule, named after Charles F. Prentice, a renowned optician. According to this rule, the prism-like power of the lens at any point on its surface equals the distance from its center, measured in centimeters, multiplied by the power of the lens in units called diopters.

There’s no prism effect at the direct center of the lens. To avoid any unwanted distortions in vision, the center of the lens should be fitted directly in front of the pupil.

This is represented in a formula: Prismatic effect = power of the lens x the distance off from the lens center in millimeters.

How is Prisms performed

Prescribing prism glasses, which can help correct vision problems, depends on the level of difference between your two eyes’ vision. The goal is to use the smallest amount of prism that can fix the difference. The base of the prism, which is the thickest part, is placed in a specific direction based on which way your eye is drifting off centre.

In layman’s terms, if your eyes are tending to drift outward (exophoria/tropia), the base of the prism in each eye should be inward. If your eyes are tending to drift inward (esophoria/tropia), the bases in both glasses should be outward. If your eyes are tending to drift upward or downward (R/L or L/R Hyper), one eye’s prism base should be lower and the other’s prism base should be higher.

Here are a few key points to remember about prism glasses:

* Spread out the corrective power evenly between both eyes.
* The base of the prism should be pointed opposite to the direction your eye is drifting.
* Prisms that range from 0.5D to 10D can be prescribed for patients with phoria, which is a common vision issue where your eyes are slightly out of alignment.
* Prisms can correct either vertical or horizontal eye misalignments, or even a combination in a diagonal direction.
* You can tolerate prisms that correct up to 6D in one eye and half in the other eye.
* Prisms can be made from glass or can be thin plastic lenses (Fresnel prisms) that stick onto your existing glasses.

Possible Complications of Prisms

Prisms are a useful tool for treating double vision and improving eye coordination. However, wearing prism glasses can sometimes lead to side effects.

Here are some potential issues you might experience when using prism glasses:

* Headaches
* Feeling of strain in your eyes
* Nausea or vomiting
* Seeing double
* Feeling confused
* Worsening of your vision

There are a few reasons why you might find prism correction glasses uncomfortable:

* Misalignment of lenses: When fitting the prisms, there may be errors in aligning the axis or the glasses’ optical center. These components can also shift out of place from simple daily use.
* Incorrect or outdated prescription: If your prism correction prescription isn’t right, or if it’s out-of-date, it can make the glasses uncomfortable. It’s important to take the necessary time in the doctor’s office to get used to the new glasses before finalizing your prescription.

What Else Should I Know About Prisms?

Prisms have a vital role in the eye care profession. They are key components in many pieces of equipment used commonly in eye examinations, from straightforward tests to more complex procedures in hospitals or eye surgery centers. Some of these instruments include the slit lamp biomicroscope, gonioscope, and ophthalmoscope, among others. They are also used in tests and treatments for conditions that affect eye alignment and movement.

A good example of prism application is the Prism Adaptation Test. This test is beneficial for patients with a type of eye misalignment where one eye turns inward, called partially accommodative esotropia. These patients, while wearing corrective lenses, are instructed to apply special prisms, and their situation is reviewed every two weeks. If the inward turn of the eye has worsened, stronger prisms are given until a steady angle is reached. Then the eye surgeon can operate, which helps in reducing the chances of under-correction.

There are also other tests involving prisms, like the Prism Alternate Cover Test, the Simultaneous Prism Cover Test, the Fusional Vergence Amplitudes Test, and the Vertical Prism Test. All these tests aim to evaluate and measure different aspects of eye alignment and movement, helping to diagnose and treat various eye conditions.

For people with low vision, prisms are used as aids in the form of convex spherical lenses. They provide a magnified image, making it easier for people with impaired vision to see. Lightweight Fresnel prisms are often chosen because they are more comfortable to wear and can provide higher magnification.

Furthermore, prisms are used in several other conditions and scenarios. For example, they can be used in conditions like age-related macular degeneration, a common eye disorder among the elderly, to enhance vision. In certain cases, they can help improve the sight of patients with neck conditions, such as severe ankylosing spondylitis. Prisms can even be used to design reading glasses for bedridden patients to allow them to read or watch television comfortably while lying down.

Prisms are also used in the management of nystagmus, a condition characterized by uncontrollable eye movements. The prisms help shift the image towards a point where the eye movements are minimal, thus improving the vision of patients with this condition. In conclusion, prisms play a critical role in different aspects of eye care, from testing and diagnosis to treatment and aiding individuals with various visual challenges.

Frequently asked questions

1. How will the prism affect my vision? 2. What is the strength of the prism and how is it measured? 3. How will the prism be positioned in my glasses? 4. Are there any potential side effects or discomfort associated with wearing prism glasses? 5. How often should I have my prism prescription checked or adjusted?

Prisms can affect the way light passes through them, causing the light to bend and split into different colors. This can be used in various applications such as creating virtual, upright images or measuring the amount of deviation caused by the prism. The effect of prisms depends on factors such as the angle of incidence, the refracting angle of the prism, and the material of the prism.

You may need prisms if you have vision problems related to how your eyes move and work together. Prisms are commonly used in orthoptics, a field of eye care that focuses on diagnosing and treating such issues. Prisms can help with conditions like double vision caused by a disease that affects the center of the eye's vision. However, it's important to note that prisms may not be suitable for everyone, and there are factors to consider such as cost and the potential for the original vision problem to worsen or become permanent over time. An eye professional can determine if prisms are necessary and appropriate for your specific situation.

One should not get prisms because they can potentially make the original vision problem worse if the eyes adapt to the prism lens, and if the underlying eye condition is still progressing, the original vision problem may come back. Additionally, continuous use of prisms can lead to an increase in the original vision problem over time and may become permanent.

There is no information provided in the text about the recovery time for prisms.

To prepare for prisms, it is important to have a detailed eye exam conducted by an eye specialist such as an orthoptist, optometrist, or ophthalmologist. They will assess your vision and determine if prisms are necessary. The specialist will then prescribe the appropriate strength and orientation of the prisms for your glasses, which can help correct vision problems.

The complications of prisms include headaches, eye strain, nausea or vomiting, seeing double, feeling confused, and worsening of vision. These issues can arise due to misalignment of lenses or an incorrect or outdated prescription.

The text does not explicitly mention the symptoms that require prisms. However, based on the information provided, prisms may be needed for individuals experiencing eye conditions such as squint (misalignment of the eyes), double vision (diplopia), weak eye convergence or divergence, uncontrolled eye movements (nystagmus), partial blindness (hemianopia), and certain medical conditions like glaucoma, retinitis pigmentosa, brain injury, and stroke. Prisms can be used for both diagnostic and treatment purposes in these cases.

There is no information in the provided text that specifically addresses the safety of using prisms during pregnancy. It is recommended to consult with a healthcare professional, such as an ophthalmologist or optometrist, for personalized advice regarding the use of prisms during pregnancy.
