Specular Microscopy

Overview of Specular Microscopy

The cornea of your eye has an important layer of cells called the endothelium. These cells are hexagonal (six-sided) and they make sure your cornea is clear and healthy. To check these cells, doctors use a special type of photography called specular microscopy. It’s a gentle procedure that doesn’t harm the eye and gives doctors a clear picture of the endothelium.

This method of examining the eyes is essential before certain types of eye surgeries. It helps doctors compare different surgical techniques and see how laser eye surgery can impact the eye. It’s also used in checking the health of a donated cornea before it’s transplanted to a patient.

Specular microscopy can help doctors diagnose a variety of diseases that affect the cells of the endothelium. These include Fuchs endothelial dystrophy, corneal dystrophies, posterior polymorphous dystrophy, pseudophakic bullous keratopathy, congenital hereditary endothelial dystrophy, viral endothelitis, ICE syndrome, trauma, uveitis and drugs that harm to the endothelium.

The technique of specular microscopy has come a long way since it was first described in 1968. Early on, it was challenging to obtain a clear image due to eye movement. But advancements in technology, especially in the 70s and 80s, made it easier for this technique to be used widely.

Modern specular microscopes are designed to be safer and more efficient. They make the exam process more comfortable and convenient. The process involves directing light towards the cornea and reflecting it off the inner layer of cells. This reflection captures an image that can be analyzed for key information like the number of cells (cell density), cell size, and shape. This information can indicate the health of the cornea and suggests if there are any issues with the cells.

specularity microscopy has become a key tool in preparing for surgeries in the eye, like cataract removal and corneal transplants. It helps doctors carefully select patients for surgery and predict how well the surgery might go. It’s also essential in managing various eye conditions and in deciding when to perform surgical interventions. It’s even used in the case of contact lens fitting, particularly for those who wear the lenses for a long time, as it helps in monitoring long-term effects on the endothelium and detecting any possible issues early on.

This method gives out important data that contribute to research and clinical practices, like assessing the effect of certain drugs on the cornea or the impact of different surgeries on the cells of the cornea. However, it does have its challenges such as needing the patient’s cooperation, having a clear cornea, and the presence of other corneal diseases. In such cases, other methods may be used. The interpretation of the images needs specific expertise and misinterpretation can lead to wrong clinical decisions. But with continuous advancements in technology, these challenges are being overcome.

With increasing interest in the development of regenerative medicine and cell-based therapies, specular microscopy is all set to play an even more significant role in the future. Its continued development and application will not only aid in diagnosis and monitoring but also optimize patient outcomes.

Anatomy and Physiology of Specular Microscopy

The corneal endothelial cells make up the part of the eye known as the cornea, which cover the front of your eye. This part of the eye is very important for focusing your vision. These cells have a special shape – like a hexagon, which helps them to evenly distribute tension and use their surface area more effectively.

The endothelial cells generally stay the same unless they get injured. If they are hurt, they extend and spread out to heal the inner surface area of the cornea. This process leads to an increase in the surface area while reducing the count of these cells. If there are different sizes of cells, it’s called polymegathism. A healthy cornea should ideally have 100% hexagonal cells but normally have 60%. However, if the cornea is under stress, the number of these cells will diminish, and the shape will also deviate from this hexagon.

Endothelial cells change as a normal part of aging. Each year the density of these cells decreases by about 0.6%. When you’re born, you usually start with around 6000 cells/mm and by the age of 5, it drops to around 3500 cells/mm.

As for the continents of the eye, each has a specific purpose. The cornea is the clear part that’s dome-shaped and is located at the front of the eye. It’s made up of some crucial layers:

The Epithelium is the outermost layer that acts as a shield to prevent dust, dirt, and bacteria from entering the eye. The good thing about this layer is it can repair itself from light scratches or injuries.

Just below that layer is Bowman’s layer. It’s tough and is made up of strong collagen fibers that protect the inner areas of the cornea. The downside is if it gets damaged, it cannot heal.

The Stroma is the densest part of the cornea, which is mostly made up of water and collagen fibers. There is a cell responsible for maintaining the collagen fibers, the keratocytes.

The Descemet’s membrane is a thin, but robust layer that provides protection for the endothelium layer. It is capable of healing slowly, even when injured.

The Endothelium, the last layer in the cornea, is responsible for maintaining the clarity of the cornea by pumping out excess water. It is important to note that these cells cannot regenerate. Therefore, any damage to this layer can have long-lasting effects on your vision.

A piece of equipment called a specular microscope is used to examine the endothelium by reflecting light off this layer, helping us see the cell density, shape, and size clearly. The healthiness of these cells serves as a good indicator of whether the cornea can stay clear and function properly.

Because of endothelial cells’ vital role and their inability to regenerate like other cells, the specular microscope has become an invaluable tool for eye doctors. They use it to diagnose and keep an eye on eye diseases, assess damage from wearing contact lenses, check if a person is a good candidate for refractive surgery, and make sure donated corneas suitable for transplant are healthy.

The endothelial cells, which make up a layer on the back of the cornea, have several roles aside from being part of the cornea’s structure. They secrete a substance to form the Descemet membrane and help ensure that the cornea remains clear and healthy. They are also in charge of the nutrient supply and the diffusion of glucose and other things in what we call the “aqueous humor,” which are the fluids in the anterior (front) chamber of the eye, through the corneal endothelium. This layer also helps keep the cornea hydrated and prevents swelling. It achieves this by acting as a semi-permeable barrier – which means it controls what can come in and go out. It also has a special pump feature, known as the Na+/K+ ATPase pump and the carbonic anhydrase pump, that assists in this task.

Why do People Need Specular Microscopy

Specular microscopy is a tool used to examine and capture images of the inside layer of the cornea, which is the clear, front window of the eye. This layer is known as the endothelium. By using this tool, doctors can help diagnose different conditions affecting the cornea. These conditions are grouped into two types: primary and secondary endotheliopathies. Primary endotheliopathies are conditions that occur on their own, not due to any other diseases in the eye or body. Secondary endotheliopathies are conditions that happen as a result of damage from other eye or body diseases.

Examples of primary endotheliopathies include corneal guttata, Fuchs endothelial corneal dystrophy, posterior polymorphous endothelial dystrophy, congenital hereditary endothelial dystrophy, iridocorneal endothelial syndrome, and senile endothelial degeneration. Examples of secondary endotheliopathies include changes in the endothelium following eye surgery, damage from contact lens wear, pseudoexfoliation induced endotheliopathy (a condition affecting the eye’s natural lens), endotheliopathy after eye inflammation or injury, dystrophy of the cornea, and drug-induced endotheliopathy.

Corneal guttata is the most common primary corneal endotheliopathy. It appears as small, dark dots on the endothelium and is often associated with aging and certain diseases, such as Fuchs endothelial dystrophy. They usually do not affect vision and can be seen in up to 70% of people over the age of 40. Corneal guttata can be seen in five stages with the help of specular microscopy.

Fuchs endothelial corneal dystrophy is characterized by the presence of guttata in the central cornea. The guttata can vary in size and number. The guttata can sometimes affect vision, but there isn’t a clear correlation between the number of guttata present and the loss of visual acuity. The presence of guttata gives the cornea a distinct image when viewed with specular microscopy.

Other conditions like posterior polymorphous endothelial dystrophy, congenital hereditary endothelial dystrophy, and iridocorneal endothelial syndrome, can be diagnosed using specular microscopy. However, some conditions can make it difficult to get a clear image of the endothelium.

In the case of secondary endotheliopathies, specular microscopy can reveal various changes to the endothelium. For example, the endothelial cells can decrease in density and change in shape after surgery. The endothelium might also show changes in people who regularly wear contact lenses or due to the impact of certain medications.

Please remember, each patient’s symptoms, eye health history, and specular microscopy results should be considered while deciding the treatment plan. Each patient is unique, and it is crucial to discuss the options, benefits, and risks with the treating eye doctor for an informed decision.

When a Person Should Avoid Specular Microscopy

There can be a number of reasons why a doctor might decide not to use a type of eye exam called specular microscopy:

• If the patient is unable to cooperate during the examination process.
• If the patient’s eye is swollen, especially the transparent layer at the front called the cornea (this is called corneal edema).
• If the patient’s cornea has an unusual shape or if the innermost layer of cells in the cornea (known as the endothelium) is irregular.
• If the patient cannot gaze straight ahead.
• If the patient’s eyes move involuntarily and rapidly (this is called nystagmus).
• If the patient’s upper eyelid droops so much that it covers part of the eye (known as severe ptosis).

Specular microscopy is a key diagnostic examination used by eye doctors to look at the cornea’s endothelium. It’s a non-invasive test that gives eye doctors valuable information about the density, shape, and overall health of the cells inside the cornea. This data can help them diagnose conditions that affect these cells, check a person’s eyes before they have eye surgery, and monitor their eyes after surgery.

However, this examination is not suitable in all situations. Some conditions can make specular microscopy risky or the results unreliable or hard to interpret.

Complete reasons why this test should not be done include:

• Severe corneal opacification: When the cornea is clouded over due to swelling, scarring, or deterioration, the machine can’t capture clear images of the inside of the cornea. This is because the light necessary for the imaging cannot get through the cornea effectively.
• Active ocular infections: Infections in the eye can get worse or spread if you use eye instruments, like the ones used in this exam. This is especially risky in cases of viral, bacterial, or fungal keratitis, which is an infection of the cornea.
• Fresh eye injuries: If the eye has been recently injured, introducing any instruments, even non-contact types, might cause further harm or infection. In these situations, it’s best to wait until the eye has healed properly.

There are also some situations that make conducting the test a challenge, but not completely impossible (known as relative contraindications):

• Shallow anterior chamber: If the front part of the eye has little fluid, performing the test might harm the cornea. Non-contact specular microscopy might be safer, but it requires the patient to cooperate more and to position themselves better.
• Severe photophobia: If the patient is very sensitive to light, they might find the bright light required for the test uncomfortable or impossible to tolerate. In these cases, the test might distress the patient and therefore not be successful.
• Pediatric Patients and Uncooperative Patients: The patient needs to keep their eyes open and stay still for several seconds for the test to work. Hence, children, infants, or patients who cannot cooperate due to cognitive or psychiatric reasons might not be able to have the exam.
• Advanced corneal dystrophies: In the advanced stages of certain diseases that affect the cells inside the cornea, such as Fuchs endothelial corneal dystrophy, the changes can make it difficult to get useful measurements or images. This is especially true if the cornea is very swollen.

If specular microscopy can’t be done or isn’t suitable, there are other ways to diagnose conditions affecting the eye. For instance, optical coherence tomography (OCT) can provide useful data about the cornea and its layers without direct contact or bright light. An ultrasound can measure the thickness of the cornea, indirectly indicating the health of the cells inside the cornea, especially in cases of swelling.

Doctors must weigh up each patient’s condition, the pros and cons of specular microscopy, and the availability of other ways to diagnose conditions affecting the eye before deciding what to do. The safety and comfort of the patient, and the quality of the diagnostic data should guide the choice of the doctor.

Equipment used for Specular Microscopy

A contact specular microscope is a type of device used to look at the cornea (the clear, front part of your eye). This special microscope uses a contact lens and a fluid that helps it connect and ‘mimic’ the cornea’s properties. This method allows a very clear view of the cornea, but it does count the contact lens as part of the cornea’s thickness. This lens also replaces the cornea’s reflection, giving a clear image with good resolution. The downside of this method is that it can be uncomfortable for the patient, and there’s a chance of infection if everything isn’t sterilized properly. Also, if the cornea is diseased, this method can lead to distorted or misleading results.

The ‘non-contact specular microscope’ avoids touching the eye by altering the angle of light that hits the cornea. This method moves the review of the front surface to the side, reducing reflection. It’s generally more comfortable for the patient, has a lower risk of infection, and gives a more extensive view of the cornea.

The ‘wide field specular microscope’ is a more advanced version. It uses a scanning mirror to capture a larger part of the cornea at one time (about 800 micrometers). This faster oscillating mirror allows a continuous view of a larger area, making the picture 10 to 15 times larger. Because the viewer can capture more area at once, it gives higher resolution images that are less affected by eye movements. It provides a more accurate cell count and allows for easy assessment of the cornea’s topography (its shape and structures). This ultimately makes it easier to focus on specific parts of the endothelium (the thin layer on the inside of the cornea).

Who is needed to perform Specular Microscopy ?

It’s crucial for medical technicians to have adequate training and understanding of a process called specular microscopy. This helps them provide better care for patients. Specular microscopy is a test that specialists use to examine your eyes’ health, particularly the cornea (the clear front surface).

Also, you have optometrists, who are like eye doctors. They help evaluate a person’s vision and how the eyes focus. They assist in figuring out the extent of your eye or vision issue. Their findings can then be used to prescribe eyeglasses or contact lenses as required.

Then you have an eye surgeon who specializes in corneal surgeries. These surgeons are skilled in evaluating results from the specular microscopy test and can spot problems in the cornea’s inner layer — the endothelium. Once they identify the exact problem in your eye, they can move forward with the appropriate treatment plan.

Moreover, some eye care professionals play a key role in counseling patients and following up on their treatment progress. Their role involves helping patients understand their conditions, the reasons behind recommended treatments, and what they can do to promote their eye health after the treatment.

Preparing for Specular Microscopy

The process of getting ready for a specular microscopy, which is an eye examination, involves numerous steps which are taken to make sure the patient is comfortable and that the exam results are correct. Here’s a simplified outline for preparation:

Before the Examination:

• Patient Education: The process of the exam is thoroughly explained to the patient so they understand why and what will happen during it. Good communication can help ease any worries and encourages the patient to participate willingly.
• Reviewing Medical History: The patient’s overall and eye-related medical history is reviewed. Any conditions that might interfere with specular microscopy are particularly noted.
• Checking for Contraindications: Contraindications are conditions that make the exam unsafe. Any clear contraindications, like active eye infections or serious damage to the cornea (the transparent front part of the eye), are ruled out. Other possible contraindications are evaluated and talked about with the patient.
• Consent: Informed consent is gathered after explaining the risks, benefits, and any alternatives to the examination.

On the Day of the Examination:

• Patient Arrival: When the patient arrives for the exam, consent is confirmed once again, and any last-minute questions are answered.
• Topical Anesthetic: In some cases, a topical anesthetic (a drug that numbs a specific area) may be applied to numb the cornea to ensure the patient is comfortable during the examination. This is typically not required for non-contact methods.
• Patient Positioning: The patient sits comfortably at the microscope, with their chin in the chin rest and forehead against the support. Proper alignment is very important for getting clear images.
• Fixation Target: The patient’s eye is directed towards a specific focal point, helping to keep the eye stable and well-aligned during the image capturing process.

During the Examination:

• Image Acquisition: Images of the corneal endothelium, which is the thin layer on the inside of the cornea, are taken. The patient must stay still during this time to help ensure the images are clear. More than one image may be taken to guarantee accuracy.
• Patient Instructions: Clear instructions are given to the patient during the exam. For instance, they may be asked to blink normally and keep their eyes open while the image is being captured.

After the Examination:

• Patient Comfort: After the exam, the patient is asked about their comfort level. This is particularly important if the contact method was used, as the eye might feel irritated once the numbness wears off.
• Aftercare Instructions: If anesthetic drops were used, the patient should avoid rubbing the eye until they regain full sensation. If non-contact methods were used, no specific aftercare is typically needed.
• Data Analysis: Once the patient has gone, the images taken during the exam are studied to evaluate the number of cells in the endothelium, variation in cell size, and to check for the presence of any abnormal cells or patterns.

By preparing carefully in these ways, doctors can increase the chances of a successful procedure and a reliable evaluation of the corneal endothelium.

How is Specular Microscopy performed

Before the procedure begins, the doctor makes sure to explain everything thoroughly to the patient. This helps the patient understand what’s happening and feel more at ease. The first step of this process involves a close look at the cornea–the outer layer of the eye. This requires examining all parts of the cornea–center, top, bottom, and sides.

The tool used for this is a special kind of light-reflecting microscope, known as a specular microscope. It works by shining a narrow beam of light onto the cornea. The light bounces back off the eye, creating an image. This image is possible due to the difference between the watery fluid (the aqueous humor) and the back layer of cells (the endothelial cells) of the cornea.

However, only a tiny fraction (0.02%) of the light beam bounces back. If a wider beam of light is used, it can bounce off the other layers impeding clear view of the endothelium. Four distinct areas (or zones) can be seen using the microscope:

* Zone 1: Outermost layer of the cornea or lens fluid
* Zone 2: The cornea’s thicker middle layer (stroma)
* Zone 3: Back layer of the cornea (Endothelium)
* Zone 4: Clear fluid present in the front of the eye (aqueous humor)

There are dark and light boundaries visible in the image as well. The dark area between zone 3 and 4, and the light between zone 3 and 2.

Different techniques can be used to study the endothelium in detail. This can include counting the number of cells a certain area (frame method), visually comparing cell patterns (comparison method), and locating the meeting point of the sides of the endothelial cell image (corner method). Each method has its own accuracy, like the fixed frame method might make errors when there are many border cells present.

Other methods like tracing the individual cell areas and studying digested cells can also be done. Using technology and computers can help assess certain features of cells, but the accuracy depends on the image quality. Factors that can influence the quality of the scan include effects such as abnormalities in tear production, scar tissue in the cornea, guttae (bumps in the eye), and the condition of the endothelial layer itself.

By making use of automated specular microscopy, the process is streamlined, allowing for automatic analysis of individual layers of cells. However, this method might not work as well when the cell borders are hard to see. In those cases, a manual count is needed. The varying judgments of different observers can lead to differences in results, up to 6% for excellent quality images and 6% to 11% for acceptable quality images.

Possible Complications of Specular Microscopy

Specular microscopy is a safe and easy procedure used to check the health of the back layer of your cornea, which is the clear, front surface of your eye. This test has very few risks involved, especially since most of these tests are done without touching your eye. However, like every medical procedure, there could be some complications:

If the doctor uses a version of the test that involves touching your cornea (called contact specular microscopy), you have a small chance of scratching your cornea. This could give you the feeling that something is stuck in your eye and can slightly increase the chance of getting an eye infection. While infections are really rare, they can occur if any bugs are introduced to the surface of your eye, particularly if the equipment is not cleaned properly.

For the more common non-touch version of the test (noncontact specular microscopy), you might find the bright light uncomfortable, especially if you’re sensitive to light. You may also feel tired in your eyes or get a headache from looking at one spot for a long time while the doctor takes pictures of your cornea.

There are also some general complications for both types of the test, which can include an allergic reaction to the numbing eyedrops (if used), tearing or blinking because of the bright light or the closeness of the equipment, which might make it harder to get a good picture of your cornea. Some people may feel worried or stressed about having an instrument close to their eye, more so for the version of the test that involves contact.

People who have certain pre-existing eye conditions or who recently had eye surgery might be at a slightly higher risk of complications for the contact version of this test. However, complications are extremely rare with the non-contact version of the test and, if they do occur, they’re usually minor and can be sorted out easily with the right care. The test should be done by trained personnel and by carefully selecting and preparing patients for the procedure, the risk of complications can be further reduced.

What Else Should I Know About Specular Microscopy ?

Specular microscopy is a special type of eye examination that helps eye doctors look at the back layer of the cornea, called the endothelium. Usually, this test is a bit tricky to perform in patients who have minor, uncontrollable eye movements. The results provide details on the appearance but do not explain how these cells are working. Nevertheless, it is a crucial tool that has helped change the way we treat various corneal diseases and conditions.

This state-of-the-art, non-invasive technique gives eye doctors a clear understanding of your eye’s health by providing important numbers (quantitative) and descriptive (qualitative) information about the endothelial cells. Don’t worry if these terms are new to you; let’s break them down together:

Endothelial Cell Density or ECD tells us about the number of cells at the back of your cornea. A high number is always a good sign; a healthy adult cornea usually has an ECD of 2500 to 3000 cells per square millimeter. A low ECD could be an early sign that the endothelium isn’t working as it should.

Cell morphology refers to cell size and shape. Normal cells tend to be uniform in size and have a hexagonal shape. Changes in cell size (polymegathism) or shape (pleomorphism) can signal cell stress or disease.

Before eye surgery, it’s important to know if the endothelium can handle the stress of an operation. This test also helps to offer a glimpse into how well your eye might heal after surgery.

After eye surgery, this test is used to monitor the healing process, particularly after a corneal transplant, because it can detect any signs that the new cornea isn’t doing well. Also, it’s helpful to monitor for any possible damage caused by the placement of a new lens after cataract surgery.

If, like many folks, you wear contact lenses, specular microscopy can check that the lens material or fit isn’t harming your endothelium. It also helps monitor for any signs of swelling or fluid accumulation in the cornea due to medication-related damage.

This technique is important for research because of its ability to capture essential data about the health of your cornea.

To conclude, specular microscopy is an essential tool in modern eye care. It plays a significant role in managing corneal conditions, enhancing surgical outcomes, and contributing to our broader understanding of eye health. So, the next time you head in for an eye check-up, it’s likely you might encounter this ingenious piece of technology!
